Mash System
Mash/ Lauter+ Brew Kettle/ Whirlpool + HLT
Material: 304 stainless steel;
Total volume: 1250L, effective volume 1000L;
3. Shape: upper dish head, cylindrical barrel, shallow cone bottom;
4. Manhole: glass manhole with sight light;
5. Insulation material: polyurethane, rock wool insulation layer thickness 80mm;
6. Heating method: Support Steam or heat up with hot water.
7. Control system: The control cabinet automatically controls the temperature and controls the opening and closing of the upper stirring motor.
Fermentation System
Fermentation System
1. Total volume: 1250L. Effective volume: 1000L;
2. Material: food grade stainless steel SUS304;
3. Cylinder design: cylinder, cylinder thickness: 3.0mm barrel outer thickness: 2.0mm;
4. Manhole: the side manhole;
5. The upper part is equipped with a hop add port, a breathing valve, and a carbon dioxide inflation port at the bottom.
6. Insulation material, polyurethane foam, thickness: 80mm;
7. Cooling method: Miller plate jacket double cooling
8. Pressure: design pressure 3bar, working pressure 1.5-2bar;
9. Lower cone design: cone seal 60° (for yeast discharge);
10. Cleaning method: matching cip cleaning car uses fixed all-round rotating cleaning ball;
11. Temperature measurement method: PT100 platinum resistance,
Packaging & Shipping
We can provide services to assist you in transporting equipment. We have regular cargo agents and are familiar with the transportation process, which can save you transportation costs and ensure the safety of equipment.
Company Information
Shandong Zunhuang Brewing Equipment Co., Ltd
v 1. Shandong Zunhuang Brewing Equipment Co., Ltd, located in Jinan city(China, mainland), is a professional beer equipment, fruit wine equipment manufacturer in China. Shandong Zunhuang could provide the turnkey project for customer, including Production→ Inspection→ Packing & Shipping→ Installation &Training → After Sales.
v 2. The equipment has exported more than 60 countries and regions, including the United States, Spain, Canada, Sweden, Denmark, Russia, India, Brazil, and other countries.
